The machine performs at grades up to 30 per cent.
The APR 49/20 is heavier than most of the vibratory plates with the exception of the APR 59/20.
Working widths of 450 mm can be broadened with extensions of 75 mm and 150 mm. The engine hood is durable and protective but also grants great accessibility for servicing.
WEIGHT & DIMENSIONS | |
---|---|
MACHINE WEIGHT | 391 kg |
WITH EXTENSION PLATES 75 mm | 413 kg |
WITH EXTENSION PLATES 150 mm | 424 kg |
A = BASE PLATE LENGTH | 450 mm |
B = MACHINE LENGTH | 898 mm |
C = WITH HANDLE | 1485 mm |
D = MACHINE HEIGHT | 817 mm |
E = HANDLE HEIGHT (WORK) | 1000 mm |
F = HANDLE HEIGHT (TRANSPORT) | 1285 mm |
G = MACHINE WIDTH | 450 mm |
ENGINE | |
---|---|
ENGINE | Hatz 1B40 |
FUEL | Diesel |
ENGINE OUTPUT | 6.6 kW / 8.8 HP |
AT RPM | 2900 |
COMPACTION FORCES | |
---|---|
MAX. VIBRATION FREQUENCY | 65 Hz |
MAX. CENTRIFUGAL FORCE | 49 kN |
WORKING SURFACE | 945 m²/h |
WITH EXTENSION PLATES 75 mm | 1260 m²/h |
WITH EXTENSION PLATES 150 mm | 1575 m²/h |
MISCELLANEOUS | |
---|---|
SPEED | 35 m/min |
FUEL TANK | 5 l |
GRADEABILITY | 30 % |
MAX. INCLINE TO ALL SIDES | 25 ° |
