Product Description
OCM Coil Bolts are made from high-strength steel and designed for use with coil thread nuts and inserts in concrete formwork, bridge deck forming, and precast concrete applications.
Available in standard 1/2" and 3/4" diameters up to 6" length, they offer self-cleaning coil threads for efficient performance in rugged jobsites.
Key Features
- Standard sizes: 1/2" & 3/4" diameters, lengths up to 6"
- Self-Cleaning Coil Thread – Ideal for dirty jobsites & concrete formwork
- Custom Lengths Available – Special sizes can be fabricated upon request
- Heavy-Duty Load Capacity – Safe working loads up to 9,000 lbs.
Performance Specifications
| Part No. | D Size | L Length (in.) | AC Across Flats (in.) | Weight per 100 pcs (lbs.) | Safe Working Load (lbs.) |
|---|---|---|---|---|---|
| 50A150CBH0P | 1/2" | 1-1/2" | 3/4" | 10.6 | 4,125 |
| 50A200CBH0P | 1/2" | 2" | 3/4" | 12.8 | 4,125 |
| 50A300CBH0P | 1/2" | 3" | 3/4" | 17.1 | 4,125 |
| 50A400CBH0P | 1/2" | 4" | 3/4" | 21.6 | 4,125 |
| 50A600CBH0P | 1/2" | 6" | 3/4" | 30.7 | 4,125 |
| 75S200CBH0P | 3/4" | 2" | 1-1/8" | 32.8 | 9,000 |
| 75S300CBH0P | 3/4" | 3" | 1-1/8" | 42.7 | 9,000 |
| 75S600CBH0P | 3/4" | 6" | 1-1/8" | 72.4 | 9,000 |
| 62S200CBH0P | 5/8" | 2" | 1" | 21.8 | 7,500 |
| 62S400CBH0P | 5/8" | 4" | 1" | 35.4 | 7,500 |
Why Choose OCM Coil Bolts?
Reliable & Durable – Made from high-strength steel for demanding applications
Self-Cleaning Thread Design – Enhances performance in concrete environments
Versatile Applications – Ideal for concrete formwork, precast concrete, and bridge deck forming
Safety Factor Built-In – Approx. 2:1 safety factor ensures secure load handling
Whether you need short-term or long-term fastening solutions, OCM Coil Bolts provide strength, reliability, and ease of use for your toughest concrete projects.
